Compact, Durable & High-Performance End-Suction Pump for Reliable Fluid Transfer
| Model | GT 350-96 |
|---|---|
| Power | 1/3 HP (0.25 kW) TEFC Electric Motor |
| Max Flow | Up to 90 GPM (≈20 m³/h) – typical range 33-90 GPM |
| Max Head | Up to 65 ft (≈20 m / 28 PSI) |
| Inlet/Outlet | 3/4" NPT Suction / 1/2" NPT Discharge |
| Materials | 300 Series Stainless Steel (Casing, Adapter, Impeller), Viton Mechanical Seal & O-Ring |
| Voltage/Phase | 115/230V, Single Phase |
| RPM | 3450 |
| Design | Horizontal Close-Coupled, End-Suction, Pull-from-Rear, Non-Self-Priming |
| SKU | 350-96 |
The GT 350-96 is a compact, durable stainless steel straight centrifugal pump designed for continuous-duty, low-pressure applications in industrial, commercial, and general service settings. Ideal for liquid transfer, circulation, cooling, chemical processing, and dirty water handling (semi-solids up to 1/8" diameter). The close-coupled design mounts directly to the motor for easy installation and minimal footprint.
Features a corrosion-resistant 300 Series stainless steel construction, self-cleaning semi-open impeller, Viton seals for chemical resistance, and pull-from-rear service without disturbing piping. Requires flooded suction (not self-priming).
Understand how the pump performs: Flow decreases as head (pressure) increases. Here are typical performance curves for the GT 350-96 and similar small stainless steel centrifugal models:
Here are real-world examples of pump performance curves:High-Flow Performance Curve (up to ~74 m³/h / 326 US gpm)
Reference points include CT EF-110, CT DG-224, CT DF-224 series equivalents showing excellent efficiency at higher capacities.
Low-Flow / Fine Resolution Performance Curve
Detailed view for lower flow rates, highlighting smooth operation down to ~5–20 m³/h with corresponding head values (CT CE-114, CT CC-114, CT AA-024, etc.).
Q: Is this pump self-priming? A: No—requires flooded suction; use a foot valve or priming if needed on suction side.
Q: What liquids can it handle? A: Clean water, light chemicals, dirty water with small semi-solids (up to 1/8"); temperatures 40–200°F; check compatibility with Viton seals.
